IP67 Waterproof LED Driver Engineer 12V 20W 1.67A Underground Light Strips Light

Quick Detail:

• Engineering Waterproof type aluminum housing dusk
• AC/DC switching 12V 20W 1.67A single-switch LED driver
• AC input voltage: 100~130V or 170~250V
• 1600V High voltage test, full loading test and old aging test
• Constant voltage driver apply for outdoors LED light strip, light box
• IP67 grade
• CE, ETL approvals
• 3 Years Warranty
• Size: 18*3.0*2.0CM & Weight: 200g

Description:

IP67 Waterproof series have two series--engineering type and ultra thin type, Widely used in LED industrial project, communications power, aerospace, industrial control systems, post communications, medical equipment and other industrial and commercial fields. All the products adopt PWM high-frequency pulse width modulation technology, mature standardized production, strict 100% load-carrying aging, high and low voltage impact experiments and complete test records for development & production of LED driver through strictly quality control system and highly responsible attitude, thus have a good quality feedback during application.

Such engineering waterproof led drivers mainly have 12V and 24V series with 20W, 30W, 40W,50W, 60W,80W,100W,200W,250W,300W,400W,450W,500W,550W,600W etc. they are mainly used for LED light strip, light box, module, signboard light, line light, wall wash light, underground light, protective tube and so on.

Specifications:

Notices:

1. Input voltage should be within the specified voltage range (for examples: input voltage 220VAC).

2. Prohibited to be used in the high temperature environment, power port is the thermal vents, wind 50CM range, please do not place other objects, make sure that the power should have good thermal dissipation space environment.

3. Prohibited to install power supply in the presence of flammable materials (such as wood products, flammable plastic, etc), to stay away from petrol stations or where prohibited Fireworks.

4. Accurate calculation of load power, peak use, suggested user to use power supply based on power 80% load, do not overload.

5. Power supply have built-in short circuit protection function, when output short circuit, the power will automatically enter the status. Power off after 1 minute and then power on.

6. For safety, properly grounded, the output power cable must be ≥2.5mm²

7. Strictly in accordance with the position indicated by the output terminals of the power supply. It must be firm, check the output line and prohibited to be reversed (input "220VAC" main line, output "+" loaded for positive cathode, output "-" load for negative cathode).

8. Before power, check that the line voltage is compatible with the operating voltage with multimeter (voltage: 220VAC) recognized before it can be closed.

9. Power firm installed vertically (vertically in a place easy to wire the power supply, cover to cover, to be water proof)

Engineering Waterproof LED drivers 12V 24V related models list:

Applications:

Widely used in LED Lighting, LED display, LED strips, LED advertisement screen, LED sign, LED night light, LED lamp house, LED decoration, LED wall light, LED street light , LED wall light, LED backlight, offices , hospital , schools , factories , shopping malls, supermarkets, kitchen, fair cabinet and so on.

FAQ

1. How many kinds of led drivers you produce?

A: There are many kinds of led drivers: indoor type, rain proof type, waterproof type, ultra thin type, high power type.

2. Do you have CE, ETL approval?

A: Most of products have CE approval, some products have ETL approval.

3. Can I place a sample order?

A: Yes, sample order is available after full test and before delivery. If big quantity, it maybe need 12-18 working days.

4. What about the lead time?

A: 3-5 days for Sample, 8-12 working days for mass production.

5. Which tests do you carry out in your factory?

A: We usually do overload test, 1600V high voltage test and 100% old age test.

6. What is MOQ for led driver?

A: MOQ usually is 100-200pcs except sample order.

7. How do you ship the goods and how long does it take to arrive?

A: We ship by sea, by railway or by sea. If samples, always by express such as FEDEX or DHL etc. It all depends.

8. How about the payment terms?

A: T/T for sample order and small quantity order and L/C for large quantity order.

9. How to start an order with each other?

A: Know your true requirements or application fully, quote based on your requirements and our suggestions, confirms the samples and places deposit for formal order and we arrange the mass production.

10. OEM and ODM is acceptable?

A: Yes. Our cooperation is flexible, OEM or ODM is acceptable.

11: Do you offer warranty period for the products as a part of after sale service?

A: Yes, we offer 3 years warranty after delivery.

8. How to deal with the faulty?

Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.

Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
